Raw Material
Our Regulator are manufactured of high grade components
| Parameter |
Details |
RITSUKA |
Chinese Product |
RITSUKA Advantage |
| BOP |
Outer Shell |
Aluminum with fins |
Aluminum with thin Fins |
High Heat dispersion capacity |
| Sealant |
Quartz with Resin |
Sand and Resin |
Good Heat absorption capacity |
| Plug |
PA66 |
ABS |
Heat proof, fire proof also life of plug is better then ABS |
| PCB Board |
Double Panel with Heat sink |
Single Panelr |
Proper assembly of electronic component, with heat sink |
| Mosfet/Transistors |
Mosfet |
Transistors |
High Power and reduce the chances of fuse |
| Resistance |
Taiwanese Diode |
Chinese Product |
Can work from -40 C to 105 C, Chinese product get short in high heat |
| Transformer |
Taiwanese |
Chinese Product |
Made by copper Chinese are made by Iron |
| Capacitors |
400V155J |
400V105J |
Enough power to run at low RPM |
| I.C. |
Philips |
Chinese Product |
Error free programming |
Manufacturing
All our product manufacturing is done as per GB standards. Here’s a comparison of our product from the Chinese product.
| Parameter |
Details |
RITSUKA |
Chinese Product |
RITSUKA Advantage |
| Manufacturing as per GB standard |
Circuit Diagram |
In-house by computerized machine |
Outsourced |
Better controlling of design and circuit |
| Assembly of Resistance |
In-house in controlled environment |
In-house with normal environment |
Increase life of small parts |
| Assembly of Transformer |
In-house in controlled environment |
In-house with normal atmosphere |
Increase life of small parts |
| Assemble the rest product |
In-house in controlled environment |
In-house with normal atmosphere |
Increase life of small parts |
| Soldering |
In-house with temperature control machine |
In-house without temperature control machine |
Circuit board can heat and fuse the small component |
| Cutting extra wire |
By pneumatic machine |
By hand operation |
Correct cutting |
| Sealing |
Quartz with Resin by automatic machine |
Sand with Resin by hand |
Correct filling of resin to give long life of Regulator |
Testing
Each of our carefully manufactured Regulators are further tested on international standards. We are passionate about creating the spare parts in the most brilliant way possible and our 100% quality inspection of products during production ensures quality product.
| Parameter |
Details |
RITSUKA |
Chinese Product |
RITSUKA Advantage |
| Testing Standard |
Incoming Quality Inspection |
100% inspection of incoming raw material |
No testing |
This ensure the incoming parts is within tolerance limit |
| In process |
100% quality check at testing machine for short circuit |
No quality check, since it requires extra manpower/extra cost |
This ensure the error free circuit |
| In process |
100% quality check of semi finish goods |
Checked only on sample basis |
100% ensure of correct goods |
| In process |
Check the voltage of transformer |
No quality check, since it requires extra manpower/extra cost |
Defect free product to customer. |
| 100% Final Quality Inspection |
100% quality check at test bench |
Checked only on sample basis |
100% ensure of correct goods |
Short Circuit Test
This test is performed to check the correct assembly of component circuit.
| Parameter |
Details |
RITSUKA |
Chinese Product |
RITSUKA Advantage |
| Testing Standard |
Short Circuit Test |
To ensure the correct assembly of components |
No testing |
- Ensure error free circuit.
- Long life of components.
|
I.C. Programming Testing
This test is performed to check the programming of I.C.
| Parameter |
Details |
RITSUKA |
Chinese Product |
RITSUKA Advantage |
| Testing Standard |
I.C. Programming Testing |
To check the programming of I.C. |
No testing |
- To ensure the programming of I.C.
|
Pre-Dispatch Inspection
This test is performed to check the performance of Regulator.
| Parameter |
Details |
RITSUKA |
Chinese Product |
RITSUKA Advantage |
| Testing Standard |
Pre-Dispatch Inspection |
To check the performance of Regulator |
On Sampling basis |
- Error free product to Client.
- Defect free product for final inspection.
|
Final Running Testing
This test is performed to check the Life of Regulator.
| Parameter |
Details |
RITSUKA |
Chinese Product |
RITSUKA Advantage |
| Testing Standard |
Final Running Testing |
To check the life of CDI |
No testing |
- Long life service product to client
|
